Abstract

The Internally Geared Screw Machine (IGSM) is a relatively novel and promising type of positive displacement compressor concept that takes inspiration from classic gerotor pumps. The IGSM uses two rotors rotating in the same direction about parallel axes while maintaining continuous contact between both rotors which isolates several working chambers. By using ported end plate, the IGSM can determine the timing of the fluid entering and exiting the working chamber. There are several key advantages to the IGSM over traditional twin-screw compressors including reduction of the rotor to casting leakage, elimination of the blow hole area, reduction in sliding velocity at the point of contact, and a uniform circumferential rotor temperature profile. Although there is some research regarding the geometric profiling and chamber modeling of this type of machine, there is no research currently available on the pressure pulsation and vibration characteristics of the IGSM. The purpose of this paper is to provide an initial look into the pressure pulsation and vibration characteristics of the IGSM and how they differ from that of a traditional twin-screw machine. By explicating the key differences between the IGSM and the industry standard twin-screw compressor, this paper aims to better understand an important yet underdeveloped area of IGSM design.

Publication Type:	Conference or Workshop Item (Paper)
Additional Information:	Content from this work may be used under the terms of the Creative Commons Attribution 4.0 licence. Any further distribution of this work must maintain attribution to the author(s) and the title of the work, journal citation and DOI.
Subjects:	T Technology > TJ Mechanical engineering and machinery
Departments:	School of Science & Technology School of Science & Technology > Department of Engineering
