Abstract

The internally geared screw machine represents a novel type of positive displacement compressor which consists of an inner and outer rotor. Both rotors rotate in the same direction but are each centered on offset parallel axes. The rotor profiles are designed to create multiple continuous contact points between the rotors, forming several separate working chambers whose volumes vary from minimum to maximum and back to minimum during a single rotation of the outer rotor. For a gas or two-phase working fluid, adjusting the discharge port geometry allows internal compression to occur before discharge. Previous research has focused on using the well-known rotor profling method, which employs a circular pin to generate the inner and outer rotor profiles. Although the rack method for rotor profile generation has been described and investigated for conventional screw machine rotor profiles, it has never been applied to internally geared screw machine profile generation. This paper provides an initial description and application of the rack method for generating internally geared screw machine profiles. Potential benefits of using the rack method compared to conventional methods for rotor profile generation in internally geared machines are discussed. Additionally, the limitations of using the rack method for internal gearing are presented and illustrated through various examples and applications.

Publication Type:	Conference or Workshop Item (Paper)
Additional Information:	Content from this work may be used under the terms of theCreative Commons Attribution 4.0 licence. Any further distribution of this work must maintain attribution to the author(s) and the title of the work, journal citation and DOI. Published under licence by IOP Publishing Ltd
Subjects:	T Technology > TJ Mechanical engineering and machinery
Departments:	School of Science & Technology School of Science & Technology > Department of Engineering
